EBR 1190 RX 2015 vs. EBR 1190 SX 2015

Technical Specifications EBR 1190 RX 2015 compared to EBR 1190 SX 2015

EBR 1190 RX 2015

EBR 1190 SX 2015

Show all

Same only

Differences

EBR 1190 RX 2015

EBR 1190 SX 2015

Engine and Drive Train

Bore	Bore	106 mm	Bore	106 mm
Stroke	Stroke	67.5 mm	Stroke	67.5 mm
Engine power	Engine power	185 HP	Engine power	185 HP
Rpm at Max. Power	Rpm at Max. Power	10,600 rpm	Rpm at Max. Power	10,600 rpm
Torque	Torque	138 Nm	Torque	138 Nm
Rpm at Torque	Rpm at Torque	8,200 rpm	Rpm at Torque	8,200 rpm
Compression Ratio	Compression Ratio	13.4	Compression Ratio	13.4
Transmission	Transmission	Chain	Transmission	Chain
Number of gears	Number of gears	6	Number of gears	6
Cylinders	Cylinders	2	Cylinders	2
Valves per cylinder	Valves per cylinder	4	Valves per cylinder	4
Cooling	Cooling	liquid	Cooling	liquid
Displacement	Displacement	1,190 ccm	Displacement	1,190 ccm

Suspension Front

Front suspension	Front suspension	Upside-Down telescopic fork	Front suspension	Upside-Down telescopic fork
Technology	Technology	Big Piston	Technology	Big Piston
Brand	Brand	Showa	Brand	Showa

Suspension Rear

Shock mount	Shock mount	direct	Shock mount	direct
Brand	Brand	Showa	Brand	Showa

Brakes Front

Piston	Piston	Eight pistons	Piston	Eight pistons
Shock mount	Shock mount	Fixed caliper	Shock mount	Fixed caliper

Brakes Rear

Type	Type	Disc	Type	Disc
Piston	Piston	Double piston	Piston	Double piston

Dimensions and Weights

Front tyre width	Front tyre width	120 mm	Front tyre width	120 mm
Front tyre height	Front tyre height	70 %	Front tyre height	70 %
Front tyre diameter	Front tyre diameter	19 inch	Front tyre diameter	19 inch
Rear tyre width	Rear tyre width	190 mm	Rear tyre width	190 mm
Rear tyre height	Rear tyre height	55 %	Rear tyre height	55 %
Rear tyre diameter	Rear tyre diameter	17 inch	Rear tyre diameter	17 inch
Length	Length	2,040 mm	Length	2,040 mm
Width	Width	737 mm	Width	810 mm
Height	Height	1,110 mm	Height	1,087 mm
Seat Height	Seat Height	826 mm	Seat Height	826 mm
Dry Weight	Dry Weight	190 kg	Dry Weight	188 kg
Fuel Tank Capacity	Fuel Tank Capacity	17.1 l	Fuel Tank Capacity	17.1 l
License compliancy	License compliancy	A	License compliancy	A
