Yamaha Jog-RR 2009 vs. Yamaha Jog-RR 2016
Yamaha Jog-RR 2009
Yamaha Jog-RR 2016
Loading...
Overview - Yamaha Jog-RR 2009 vs Yamaha Jog-RR 2016
Yamaha Jog-RR 2009
Yamaha Jog-RR 2016
Technical Specifications Yamaha Jog-RR 2009 compared to Yamaha Jog-RR 2016
Yamaha Jog-RR 2009
Yamaha Jog-RR 2016
Engine and Drive Train
Bore | Bore | 40 mm | Bore | 40 mm |
---|---|---|---|---|
Stroke | Stroke | 39.2 mm | Stroke | 39.2 mm |
Engine power | Engine power | 3 HP | Engine power | 2.9 HP |
Rpm at Max. Power | Rpm at Max. Power | 7,500 rpm | Rpm at Max. Power | 7,500 rpm |
Torque | Torque | 2.97 Nm | Torque | 2.97 Nm |
Rpm at Torque | Rpm at Torque | 6,500 rpm | Rpm at Torque | 6,500 rpm |
Compression Ratio | Compression Ratio | 11.4 | Compression Ratio | 11.4 |
Starter | Starter | Kick | Starter | Kick |
Clutch Type | Clutch Type | Centrifugal force | Clutch Type | Centrifugal force |
Ignition | Ignition | CDI | Ignition | CDI |
Displacement | Displacement | 49 ccm | Displacement | 49 ccm |
Suspension Front
Front suspension | Front suspension | Telescopic fork | Front suspension | Telescopic fork |
---|
Brakes Rear
Type | Type | Drum | Type | Drum |
---|
Dimensions and Weights
Front tyre diameter | Front tyre diameter | 12 inch | Front tyre diameter | 12 inch |
---|---|---|---|---|
Rear tyre diameter | Rear tyre diameter | 12 inch | Rear tyre diameter | 12 inch |
Length | Length | 1,740 mm | Length | 1,740 mm |
Width | Width | 675 mm | Width | 675 mm |
Height | Height | 1,065 mm | Height | 1,065 mm |
Wheelbase | Wheelbase | 1,210 mm | Wheelbase | 1,210 mm |
Seat Height | Seat Height | 770 mm | Seat Height | 770 mm |
Fuel Tank Capacity | Fuel Tank Capacity | 5.5 l | Fuel Tank Capacity | 5.5 l |
License compliancy | License compliancy | AM | License compliancy | AM |
