Yamaha YZ 250 LC 2015 vs. Yamaha YZ250LC 2009

Technical Specifications Yamaha YZ 250 LC 2015 compared to Yamaha YZ250LC 2009

Yamaha YZ 250 LC 2015

Yamaha YZ250LC 2009

Show all

Same only

Differences

Yamaha YZ 250 LC 2015

Yamaha YZ250LC 2009

Engine and Drive Train

Bore	Bore	66.4 mm	Bore	66.4 mm
Stroke	Stroke	72 mm	Stroke	72 mm
Compression Ratio	Compression Ratio	10.6	Compression Ratio	8.9
Starter	Starter	Kick	Starter	Kick
Clutch Type	Clutch Type	Multiplate in oil-bath	Clutch Type	Multiplate in oil-bath
Ignition	Ignition	CDI	Ignition	CDI
Transmission	Transmission	Chain	Transmission	Chain
Displacement	Displacement	249 ccm	Displacement	249 ccm

Suspension Front

Front suspension	Front suspension	Telescopic fork	Front suspension	Telescopic fork

Brakes Front

Type	Type	Single disk	Type	Single disk

Brakes Rear

Type	Type	Disc	Type	Disc

Dimensions and Weights

Front tyre diameter	Front tyre diameter	21 inch	Front tyre diameter	21 inch
Rear tyre diameter	Rear tyre diameter	19 inch	Rear tyre diameter	19 inch
Length	Length	2,184 mm	Length	2,184 mm
Width	Width	827 mm	Width	827 mm
Height	Height	1,309 mm	Height	1,309 mm
Wheelbase	Wheelbase	1,481 mm	Wheelbase	1,481 mm
Seat Height	Seat Height	997 mm	Seat Height	997 mm
Fuel Tank Capacity	Fuel Tank Capacity	8 l	Fuel Tank Capacity	8 l
