Honda CRF250L 2017 vs. Yamaha WR250F 2012

Technical Specifications Honda CRF250L 2017 compared to Yamaha WR250F 2012

Honda CRF250L 2017

Yamaha WR250F 2012

Show all

Same only

Differences

Honda CRF250L 2017

Yamaha WR250F 2012

Engine and Drive Train

Bore	Bore	76 mm	Bore	77 mm
Stroke	Stroke	55 mm	Stroke	53.6 mm
Compression Ratio	Compression Ratio	10.7	Compression Ratio	12.5
Starter	Starter	Electric	Starter	Kick
Clutch Type	Clutch Type	Multiplate in oil-bath	Clutch Type	Multiplate in oil-bath
Ignition	Ignition	Digital, Transistor	Ignition	CDI
Transmission	Transmission	Chain	Transmission	Chain
Number of gears	Number of gears	6	Number of gears	5
Cylinders	Cylinders	1	Cylinders	1
Strokes	Strokes	4-Stroke	Strokes	4-Stroke
Valves per cylinder	Valves per cylinder	4	Valves per cylinder	5
Cooling	Cooling	liquid	Cooling	liquid
Displacement	Displacement	249 ccm	Displacement	250 ccm

Suspension Front

Front suspension	Front suspension	Upside-Down telescopic fork	Front suspension	Telescopic fork

Chassis

Frame	Frame	Steel	Frame	Aluminium
Frame type	Frame type	Double cradle	Frame type	Twin Tube

Brakes Rear

Type	Type	Disc	Type	Disc

Dimensions and Weights

Length	Length	2,195 mm	Length	2,190 mm
Width	Width	815 mm	Width	825 mm
Height	Height	1,195 mm	Height	1,305 mm
Wheelbase	Wheelbase	1,445 mm	Wheelbase	1,485 mm
Seat Height	Seat Height	875 mm	Seat Height	990 mm
Fuel Tank Capacity	Fuel Tank Capacity	7.8 l	Fuel Tank Capacity	8 l
