Yamaha Grizzly 700 EPS XT-R 2024 vs. Yamaha Kodiak 700 EPS 2024

Technical Specifications Yamaha Grizzly 700 EPS XT-R 2024 compared to Yamaha Kodiak 700 EPS 2024

Yamaha Grizzly 700 EPS XT-R 2024

Yamaha Kodiak 700 EPS 2024

Show all

Same only

Differences

Yamaha Grizzly 700 EPS XT-R 2024

Yamaha Kodiak 700 EPS 2024

Engine and Drive Train

Bore	Bore	102 mm	Bore	102 mm
Stroke	Stroke	84 mm	Stroke	84 mm
Compression Ratio	Compression Ratio	10.1	Compression Ratio	10.1
Fuel system	Fuel system	Injection	Fuel system	Injection
Starter	Starter	Electric	Starter	Electric
Clutch Type	Clutch Type	Centrifugal force	Clutch Type	Centrifugal force
Ignition	Ignition	Transistor	Ignition	Transistor
Transmission	Transmission	Prop shaft	Transmission	Prop shaft
2WD	2WD	Yes	2WD	Yes
Transmission Type	Transmission Type	Automatic	Transmission Type	Automatic
Cylinders	Cylinders	1	Cylinders	1
Strokes	Strokes	4-Stroke	Strokes	4-Stroke
Valves per cylinder	Valves per cylinder	4	Valves per cylinder	4
Valves	Valves	OHC	Valves	OHC
Cooling	Cooling	liquid	Cooling	liquid
Displacement	Displacement	686 ccm	Displacement	686 ccm

Suspension Front

Front suspension	Front suspension	A-Arm	Front suspension	A-Arm
Travel	Travel	193 mm	Travel	180 mm

Suspension Rear

Suspension	Suspension	A-Arm	Suspension	A-Arm
Travel	Travel	232 mm	Travel	230 mm

Brakes Front

Type	Type	Double disk	Type	Double disk
Actuation	Actuation	Hydraulic	Actuation	Hydraulic

Brakes Rear

Type	Type	Disc	Type	Disc

Assistance Systems

Advanced Rider Assistance Systems	Advanced Rider Assistance Systems	Steering assist system	Advanced Rider Assistance Systems	Steering assist system

Dimensions and Weights

Front tyre width	Front tyre width	27 mm	Front tyre width	25 mm
Front tyre height	Front tyre height	10 %	Front tyre height	8 %
Front tyre diameter	Front tyre diameter	14 inch	Front tyre diameter	12 inch
Rear tyre width	Rear tyre width	27 mm	Rear tyre width	25 mm
Rear tyre height	Rear tyre height	10 %	Rear tyre height	10 %
Rear tyre diameter	Rear tyre diameter	14 inch	Rear tyre diameter	12 inch
Length	Length	2,070 mm	Length	2,070 mm
Width	Width	1,230 mm	Width	1,180 mm
Height	Height	1,253 mm	Height	1,240 mm
Wheelbase	Wheelbase	1,253 mm	Wheelbase	1,250 mm
Seat Height	Seat Height	860 mm	Seat Height	860 mm
Fuel Tank Capacity	Fuel Tank Capacity	18 l	Fuel Tank Capacity	18 l
