Ducati Diavel V4 2023 vs. Ducati Diavel 1260 2019

Ducati Diavel V4 2023

Ducati Diavel V4 2023

Ducati Diavel 1260 2019

Ducati Diavel 1260 2019

Loading...

Overview - Ducati Diavel V4 2023 vs Ducati Diavel 1260 2019

Ducati Diavel V4 2023

Ducati Diavel V4 2023

Ducati Diavel 1260 2019

Ducati Diavel 1260 2019

Technical Specifications Ducati Diavel V4 2023 compared to Ducati Diavel 1260 2019

Ducati Diavel V4 2023
Ducati Diavel 1260 2019
Ducati Diavel V4 2023
Ducati Diavel V4 2023
Ducati Diavel 1260 2019
Ducati Diavel 1260 2019

Engine and Drive Train

Engine typeEngine typeVEngine typeV
BoreBore83 mmBore106 mm
StrokeStroke53.5 mmStroke71.5 mm
Engine powerEngine power168 HPEngine power159 HP
Rpm at Max. PowerRpm at Max. Power10,750 rpmRpm at Max. Power9,500 rpm
TorqueTorque126 NmTorque129 Nm
Rpm at TorqueRpm at Torque7,500 rpmRpm at Torque7,500 rpm
Compression RatioCompression Ratio14 Compression Ratio13
Fuel systemFuel systemInjectionFuel systemInjection
DegreesDegrees90 Degrees90
StarterStarterElectricStarterElectric
Clutch TypeClutch TypeMultiplate in oil-bath, AntihoppingClutch TypeMultiplate in oil-bath, Antihopping
TransmissionTransmissionChainTransmissionChain
Transmission TypeTransmission TypeGearshiftTransmission TypeGearshift
Number of gearsNumber of gears6Number of gears6
CylindersCylinders4Cylinders2
StrokesStrokes4-StrokeStrokes4-Stroke
Valves per cylinderValves per cylinder4Valves per cylinder4
CoolingCoolingliquidCoolingliquid
DisplacementDisplacement1,158 ccmDisplacement1,261 ccm

Suspension Front

Front suspensionFront suspensionUpside-Down telescopic forkFront suspensionUpside-Down telescopic fork
DiameterDiameter50 mmDiameter50 mm
TravelTravel120 mmTravel120 mm
AdjustmentAdjustmentCompression, Preload, ReboundAdjustmentCompression, Preload, Rebound

Suspension Rear

SuspensionSuspensionSingle swing armSuspensionSingle swing arm
Shock absorberShock absorberMonoshockShock absorberMonoshock
BrandBrandSachsBrandMarzocchi
TravelTravel145 mmTravel130 mm
AdjustmentAdjustmentCompression, Preload, ReboundAdjustmentCompression, Preload, Rebound
MaterialMaterialAluminiumMaterialAluminium

Chassis

FrameFrameAluminiumFrameSteel
Frame typeFrame typeMonocoqueFrame typeTubular
RakeRake64 degreeRake27 degree
TrailTrail112 mmTrail120 mm

Brakes Front

TypeTypeDouble diskTypeDouble disk
DiameterDiameter330 mmDiameter320 mm
PistonPistonFour pistonsPistonFour pistons
Shock mountShock mountSemi-SchwimmsattelShock mountSemi-Schwimmsattel
ActuationActuationHydraulicActuationHydraulic
TechnologyTechnologyradial, MonoblockTechnologyradial, Monoblock
BrandBrandBremboBrandBrembo

Brakes Rear

TypeTypeDiscTypeDisc
DiameterDiameter265 mmDiameter265 mm
PistonPistonDouble pistonPistonDouble piston

Assistance Systems

Advanced Rider Assistance SystemsAdvanced Rider Assistance SystemsABS, Riding modes, Cornering ABS, Launch-Control, Ride by Wire, Shift assistant with blipper, Cruise control, Traction control, Anti-wheelieAdvanced Rider Assistance SystemsABS, Riding modes, Traction control, Anti-wheelie

Dimensions and Weights

Front tyre widthFront tyre width120 mmFront tyre width120 mm
Front tyre heightFront tyre height70 %Front tyre height70 %
Front tyre diameterFront tyre diameter17 inchFront tyre diameter17 inch
Rear tyre widthRear tyre width240 mmRear tyre width240 mm
Rear tyre heightRear tyre height45 %Rear tyre height45 %
Rear tyre diameterRear tyre diameter17 inchRear tyre diameter17 inch
WheelbaseWheelbase1,593 mmWheelbase1,600 mm
Seat HeightSeat Height790 mmSeat Height780 mm
Dry Weight (with ABS)Dry Weight (with ABS)211 kgDry Weight (with ABS)218 kg
Kerb Weight (with ABS)Kerb Weight (with ABS)236 kgKerb Weight (with ABS)244 kg
Fuel Tank CapacityFuel Tank Capacity20 lFuel Tank Capacity17 l
License compliancyLicense compliancyALicense compliancyA

Pros and Cons in comparison

Pros and Cons in comparison

Ducati Diavel V4 2023

Ducati Diavel V4 2023

With the new Diavel V4, Ducati is launching an absolute premium naked bike that its owners will be very proud of. In all aspects, it combines performance with suitability for everyday use and surprisingly high accessibility. The equipment is complete, the workmanship is of high quality and the appearance is unique. All it needs is the necessary small change.

great Granturismo V4 engine

superbly tuned suspension

powerful brakes

comprehensive electronics package

comfortable ergonomics

low fuel consumption

unique appearance

Engine runs below 2,500 revolutions

Cruise control operation could be more intuitive

Ducati Diavel 1260 2019

Ducati Diavel 1260 2019

Unfortunately, our editors did not test this model.
