Ducati Diavel V4 2023 vs. Ducati Diavel 1260 2019

Ducati Diavel V4 2023

Ducati Diavel 1260 2019

Overview - Ducati Diavel V4 2023 vs Ducati Diavel 1260 2019

Ducati Diavel V4 2023

Ducati Diavel 1260 2019

Technical Specifications Ducati Diavel V4 2023 compared to Ducati Diavel 1260 2019

Ducati Diavel V4 2023

Ducati Diavel 1260 2019

Ducati Diavel V4 2023

Ducati Diavel 1260 2019

Engine and Drive Train

Engine type	Engine type	V	Engine type	V
Bore	Bore	83 mm	Bore	106 mm
Stroke	Stroke	53.5 mm	Stroke	71.5 mm
Engine power	Engine power	168 HP	Engine power	159 HP
Rpm at Max. Power	Rpm at Max. Power	10,750 rpm	Rpm at Max. Power	9,500 rpm
Torque	Torque	126 Nm	Torque	129 Nm
Rpm at Torque	Rpm at Torque	7,500 rpm	Rpm at Torque	7,500 rpm
Compression Ratio	Compression Ratio	14	Compression Ratio	13
Fuel system	Fuel system	Injection	Fuel system	Injection
Degrees	Degrees	90	Degrees	90
Starter	Starter	Electric	Starter	Electric
Clutch Type	Clutch Type	Multiplate in oil-bath, Antihopping	Clutch Type	Multiplate in oil-bath, Antihopping
Transmission	Transmission	Chain	Transmission	Chain
Transmission Type	Transmission Type	Gearshift	Transmission Type	Gearshift
Number of gears	Number of gears	6	Number of gears	6
Cylinders	Cylinders	4	Cylinders	2
Strokes	Strokes	4-Stroke	Strokes	4-Stroke
Valves per cylinder	Valves per cylinder	4	Valves per cylinder	4
Cooling	Cooling	liquid	Cooling	liquid
Displacement	Displacement	1,158 ccm	Displacement	1,261 ccm

Suspension Front

Front suspension	Front suspension	Upside-Down telescopic fork	Front suspension	Upside-Down telescopic fork
Diameter	Diameter	50 mm	Diameter	50 mm
Travel	Travel	120 mm	Travel	120 mm
Adjustment	Adjustment	Compression, Preload, Rebound	Adjustment	Compression, Preload, Rebound

Suspension Rear

Suspension	Suspension	Single swing arm	Suspension	Single swing arm
Shock absorber	Shock absorber	Monoshock	Shock absorber	Monoshock
Brand	Brand	Sachs	Brand	Marzocchi
Travel	Travel	145 mm	Travel	130 mm
Adjustment	Adjustment	Compression, Preload, Rebound	Adjustment	Compression, Preload, Rebound
Material	Material	Aluminium	Material	Aluminium

Chassis

Frame	Frame	Aluminium	Frame	Steel
Frame type	Frame type	Monocoque	Frame type	Tubular
Rake	Rake	64 degree	Rake	27 degree
Trail	Trail	112 mm	Trail	120 mm

Brakes Front

Type	Type	Double disk	Type	Double disk
Diameter	Diameter	330 mm	Diameter	320 mm
Piston	Piston	Four pistons	Piston	Four pistons
Shock mount	Shock mount	Semi-Schwimmsattel	Shock mount	Semi-Schwimmsattel
Actuation	Actuation	Hydraulic	Actuation	Hydraulic
Technology	Technology	radial, Monoblock	Technology	radial, Monoblock
Brand	Brand	Brembo	Brand	Brembo

Brakes Rear

Type	Type	Disc	Type	Disc
Diameter	Diameter	265 mm	Diameter	265 mm
Piston	Piston	Double piston	Piston	Double piston

Assistance Systems

Advanced Rider Assistance Systems	Advanced Rider Assistance Systems	ABS, Riding modes, Cornering ABS, Launch-Control, Ride by Wire, Shift assistant with blipper, Cruise control, Traction control, Anti-wheelie	Advanced Rider Assistance Systems	ABS, Riding modes, Traction control, Anti-wheelie

Dimensions and Weights

Front tyre width	Front tyre width	120 mm	Front tyre width	120 mm
Front tyre height	Front tyre height	70 %	Front tyre height	70 %
Front tyre diameter	Front tyre diameter	17 inch	Front tyre diameter	17 inch
Rear tyre width	Rear tyre width	240 mm	Rear tyre width	240 mm
Rear tyre height	Rear tyre height	45 %	Rear tyre height	45 %
Rear tyre diameter	Rear tyre diameter	17 inch	Rear tyre diameter	17 inch
Wheelbase	Wheelbase	1,593 mm	Wheelbase	1,600 mm
Seat Height	Seat Height	790 mm	Seat Height	780 mm
Dry Weight (with ABS)	Dry Weight (with ABS)	211 kg	Dry Weight (with ABS)	218 kg
Kerb Weight (with ABS)	Kerb Weight (with ABS)	236 kg	Kerb Weight (with ABS)	244 kg
Fuel Tank Capacity	Fuel Tank Capacity	20 l	Fuel Tank Capacity	17 l
License compliancy	License compliancy	A	License compliancy	A

Pros and Cons in comparison

Ducati Diavel V4 2023

With the new Diavel V4, Ducati is launching an absolute premium naked bike that its owners will be very proud of. In all aspects, it combines performance with suitability for everyday use and surprisingly high accessibility. The equipment is complete, the workmanship is of high quality and the appearance is unique. All it needs is the necessary small change.

great Granturismo V4 engine

superbly tuned suspension

powerful brakes

comprehensive electronics package

comfortable ergonomics

low fuel consumption

unique appearance

Engine runs below 2,500 revolutions

Cruise control operation could be more intuitive
